Yealink MVC400-C4-000 videoneuvottelu

Kuvaus

MVC400 Microsoft Teams Rooms System
Microsoft Teams Rooms System for Small Rooms
Yealink MVC400 is specially designed for small conference rooms. The new generation MVC400
portfolio is the optimum choice for small meeting rooms with easy deployment, which includes
new generation high-performance MINI-PC MCore Pro, new generation touch panel MTouch E2,
and USB Video Bar UVC40. Yealink new generation MINI-PC MCore Pro combines aesthetics with
practicality, has three HDMI ports, and comes with EDID, providing a flexible and reliable
deployment solution for conference rooms. UVC40 together with 8 MEMS microphone arrays and
133 diagonal fields of view. UVC40 supports Al technologies such as face recognition, sound
localization, and speaker tracking. UVC40 can provide users with a high-quality call experience in
full-duplex mode.

Specifications
MVC400 Microsoft Teams Rooms System
Parameter Description
Package Content
• MCore Pro, Gen-3 Mini-PC
• MTouch E2, Gen-3 touch panel
• UVC40 All-in-One Video Bar
Preload
• Windows 10 loT Enterprise x64/ Windows 11* IoT Enterprise X64
• Windows 10 loT Enterprise
• Microsoft Teams Rooms App, support Skype for Business onpremise/
online and Teams meetings
• Yeallink RoomConnect
*Windows 11 will be supported in 23H2
MCore Pro, Gen-3
Mini-PC
• 11th Gen Intel® Core i5
• Memory: 8 GB (2 x 4GB)
• Storage: 128 GB SSD
• 3x HDMI video output with CEC supported
• TPM2.0
• Kernel DMA
• EDID
• Wi-Fi: IEEE 802.11 a/b/g/n/ac/ax
• Bluetooth: BT 5.2
• 1 x Yealink MTouch port (RJ45), connect to MTouch Plus / MTouch E2
• 4 x USB 3.0 Type-A
• 1 x 10/100/1000M Ethernet port
• 1 x Power port
• 1 x Security lock slot, Integrated cable management
MTouch E2 touch
panel
• 8-inch IPS screen
• 1280 x 800 resolution
• 10-point capacitive touch screen
• 3.5 mm headset jack
• Angle adjustable bracket (28° – 50°)
• 1080P/30FPS FHD for sharing
• Support wired and wireless content sharing
• Built-in Wi-Fi AP for Yealink wireless presentation device
• HDMI/USB-C HD video input
MVC400 Microsoft Teams Rooms System
UVC40 All-in-One
Video Bar
• 20 MP Camera
• 8x e-PTZ Camera
• Field of view (diagonal): 133°
• Auto Framing
• Speaker Tracking
• AI Face Enhancement
• Camera Presets
• Built-in 8 MEMS microphone array
• Yealink Noise Proof Technology
• Beamforming directed voice pickup technology
• Full-duplex technology
• Echo cancellation technology
• 1 x Yealink Microphone port (RJ-45)
• 1 x Line-in (3.5 mm)
• 1 x USB 3.0 Type-B
• 1 x USB 2.0 Type-A
• 1 x 2.5 m USB 2.0 cable
• 1 x Reset slot
• 1 x Power port
• 1 x Security lock slot, Integrated cable management
Package Features
• N.W/CTN: 6.4 kg
• G.W/CTN: 7.6 kg
• Carton Meas: 685 mm x 356 mm x 285 mm
Product
Dimension (W.D.H)
• MTouch E2: 202 mm x 151 mm x 100 mm, N.W/CTN: 1 kg
• MCore Pro: 168 mm x 197 mm x 39 mm, N.W/CTN: 1.35 kg
• UVC40: 600 mm x 68 mm x 82 mm, N.W/CTN: 2.56 kg
*This feature will be supported in future versions
